Description

XSOL 3D Laser Foot Plantar Scanner

Portable and reliable. Fast true 3D laser scan with color texture Auto landmark, arch index, measurement, and diagnostic report Custom shoes and orthotic insoles for foot clinics and retail stores.

XSOL Hardware

• FootPlantar 3D with color in non/semi/full weight
• FoamImpression and Plaster Cast
• Laser3D Scan 0s one-way

Color texture 2.0s/4.9s for normal/high resolution High resolution color can match 2D office scanner

• PC Minimum J4125 4G RAM 1080P display PCRecommended N5105 8G RAM or better
• SoftwareUI or Foot switch to activate scan
• Roomlighting (improved noise filtering than USOL)
• Heelcamera has higher resolution than USOL
• Clean3D mesh, +/- 0mm accuracy
• ScanVolume 330L X 140W X 80H mm
• Size:455L X 212W X 55H mm
• Weight:2Kg (7.1Lb)
• LoadCapacity: 180 Kg (397Lb)
• Poweradapter AC 100-240V; DC 12V/3A
• Customizablepanels design and color
• CE/FDA/PSEcertification/registration
• One-yearlimited warranty

XSOL Software

• Win10/11,doesn’t support Win7/8
• Autodiagnostic for arch type, bunion, and heel angle
• Autotracking blue-marked 1st and 5th met points
• Autotracking blue-marked 3 heel
• Marklandmarks on foot then drag points to match
• PDFFoot report with manual annotations
• User-editablereport templates, sell your own brand
• User-defineUI and icon color
• Default Translate into your own local language
• Shoesize US/UK/EU/CN/JP standards
• Exportto STL/WRL/OBJ/PLY, JPG/PNG, PDF report, CSV data files
• FTPsend order to shoe/insole fabrication
• User-defineRX form for orthopedic shoe/insole
• Developers:CMD/TCP call scanner to receive data-

-integration into your own CAD software and database

• Optionalencrypt scanners to lock files
• Alsosupport USOL, USOL-DUO and USOL-X scanners
